LC Uniboot patch cords are a specialized type of fiber optic patch cords that utilize a "single tube, dual core" structure, integrating two fibers within a single sheath to support duplex transmission. Compared to traditional LC patch cords, Uniboot cords offer higher space efficiency and more convenient polarity reversal functionality, making them ideal for high-density cabling environments such as data centers and telecommunications networks.
OS2 LC-LC Uniboot Duplex 2.0/3.0mm Multimode Fiber Optic Jumper
• Low insertion loss
• High back reflection loss
• Stable capability and high reliability
• Excellent mechanical capability
• PVC jacket as default
• Ideal solution for high-speed data transmission
• 100% inspected for optical characteristics before shipment
 |
 |
 |
|
Zirconia Ceramic Ferrule The precision ferrules can reach up to 500 times insertion lifespan. |
10/5D Min. Bend Radius The G.657.A1 fiber allows tighter cable bends for slack storage and routing. |
100-160N Tensile Strength The pull-resistant cable prevents cable breaking and prolongs the service life. |
| Fiber Type | 9/125µm Singlemode OS2 | Fiber Count | Duplex (2-fiber) |
| Connector Type | LC to LC | Polish | UPC to UPC |
| Cable Length | 1m,2m,3m … 50m or Customize | Cable Diameter | 2.0 mm |
| Tensile Strength | 70 N | Length Tolerance | +/- 1cm |
| Insertion Loss | ≤0.2dB | Return Loss | ≥50dB |
| Repeatability | ≤0.2dB | Interchangeability | ≤0.2dB |
| Jacket Material | PVC (OFNR riser-rated) | Jacket Color | Yellow |
| Environment | Operating: -20°C to 70°C Storage: -40°C to 85°C |
Compliance | Telcordia GR-326-CORE RoHS compliant |
| Application | Optical fiber communications system Optical fiber access networks Optical fiber CATV Optical fiber test equipment Optical fiber data communication |
Application | Premises Distribution Local Area Networks (LAN) Fiber-to-the-Home (FTTX) Device Terminations |
