3C-LINK's 200G QSFP-DD DAC cable primarily enables high-bandwidth 200G links and supports 200G Ethernet rate. It provides a QSFP-DD-to-QSFP-DD copper direct-attach solution. 200G QSFP-DD DAC cables are suitable for very short links and offer a cost-effective way to establish a 200-Gigabit link between QSFP-DD ports of switches/routers within racks and across adjacent racks. 3C-LINK currently offers passive copper cables in lengths of 0.5, 1, and 2 meters.
200G QSFP-DD DAC cables are suitable for very short links and offer a cost-effective way to establish a 200-Gigabit link between QSFP-DD ports of switches/routers within racks and across adjacent racks.
 |
 |
 |
Proven Performance |
Proven Compatibility |
Enjoy Massive Saving |
| When performance and reliability are vital, use our high-quality optics to build your network. 3C-LINK 200G DAC is engineered, produced, and tested in the factory for reliable end-to-end quality | There’s an easy way to verify compatibility: test in real network devices. 3C-LINK 200G DAC is tested in multi-switch devices for compatibility to ensure flawless functioning. | Compared to the original DAC cable, the 3C-LINK 200G DAC cable can save you up to 80% on project and networking cabling. You won’t find a better combination of quality and affordability. |
• Compatible with SFF 8665 and IEEE 802.3cd
• Compliant with IEEE 802.3bj 200GEBASE-CR4
• 4-Channel Full-Duplex Passive Copper Cable
• Optimized construction to minimize insertion loss and cross talk
• Supports aggregate data rates of 200Gbps(PAM4)
| OEM Part Number | QSFPDD-200G-CU-50CM QSFPDD-200G-CU-1M QSFPDD-200G-CU-2M QSFPDD-200G-CU-3M |
3C-LINK Part Number | 3C-QSFPD2-CU0.5M 3C-QSFPD2-CU1M 3C-QSFPD2-CU2M 3C-QSFPD2-CU3M |
| Form Factor | QSFPDD DAC Cable | Data Rate | 200Gbps |
| Passive or actively equalized | Passive | Supply Voltage | 3.3V |
| Cable Length | 0.5~3 meter (1.6~9.8 ft) | Cable impedance | 100 Ω |
| Cable Type | Twinax Copper Cable | Wire Gauge | 26/30AWG |
| Minimum cable bend radius | 45~60 mm | Cable Jacket Type | PVC |
| Connector | QSFP56 to QSFP56 | Digital Diagnostic Monitoring | N/A |
| Environment | Operating: 0°C to 70°C Storage: -40°C to 85°C |
Weight | 0.4 kg |
| Application | Data centers, high-end servers Enterprise wiring closets |
Compliance | IEEE802.3cd InfiniBand EDR SFF-8665, RoHS |
