400G-SR8-PNG

200G QSFP56 SR4 100m Transceiver

3C-LINK 200GE QSFP56 SR4 is a series of pluggable optical transceiver modules includes standard version ,enhanced version and liquid version. Designed for data center 200GBASE-SR4 Ethernet links reach up to 100m over 4 pairs of parallel MMF with FEC.

200G QSFP56 SR4 module

200GBASE-SR4 QSFP56 Optical Transceiver Module (MMF, 850nm, 100m, MTP/MPO, DOM)

3C-LINK QSFP56 SR4 Optical Transceiver Module is designed for 200GBASE Ethernet throughput over MTP/MPO-12 connectors using OM4 multimode fiber (MMF) with a wavelength of 850nm up to 100 meters. The transceiver is compliant with IEEE 802.3bs, 200GBASE-SR4, SFF-8636 & SFF-8665 standards. It is suitable for data centers, high performance computing networks, enterprise core and distribution layer applications.

Model No. 3C-QSFP56-SR4 Vendor Name 3C-LINK
Form Factor QSFP56 Max Data Rate 200Gbps
Wavelength 850nm Max Cable Distance 70m@OM3/100m@OM4
Connector MTP/MPO-12 or MTP/MPO-8 Fiber Type MMF
Transmitter Type VCSEL 850nm Receiver Type PIN
DDM/DOM Yes Temperature Range 0 to 70°C (32 to 158°F)
TX Power -3.0~3.0dBm Receiver Sensitivity <-7.0dBm
Powerbudget 3.5dB Receiver Overload 5.0dBm
Typical Power Consumption ≤5W Extinction Ratio >3dB
Modulation Format PAM4 CDR (Clock and Data Recovery) TX & RX Built-in CDR
Transmit and Dispersion Penalty 4.5dB Host FEC Supported
Packaging Technology COB EMC (Electromagnetic Compatibility)
Supported
ProtocolsIEEE 802.3bs, QSFP56 MSA, SFF-8665, SFF-8636, RoHS 10   Warranty 3 Years
